Inheritance diagram for hierarchical_demo_simple.ProcessorCore:

Collaboration diagram for hierarchical_demo_simple.ProcessorCore:

Public Member Functions
	__init__ (self, str name, str architecture, int core_count=4)
	__init__ (self, str name, str architecture, int core_count=4)
Public Member Functions inherited from hierarchical_demo_simple.Component
	__init__ (self, str name, ComponentCategory category)
	add_child (self, 'Component' child)
Rectangle	calculate_hierarchical_bbox (self)
int	get_total_gate_count (self)
List[ 'Component']	flatten_hierarchy (self)
	__init__ (self, str name, ComponentCategory category)
	add_child (self, 'Component' child)
Rectangle	calculate_hierarchical_bbox (self)
int	get_total_gate_count (self)
List[ 'Component']	flatten_hierarchy (self)

Public Attributes
	architecture = architecture
	core_count = core_count
Public Attributes inherited from hierarchical_demo_simple.Component
	name = name
	category = category
	position = Point(0, 0)
	bounding_box = Rectangle(0, 0, 1, 1)
list	children = []
Optional[]	parent = None
dict	properties = {}
